The Africa Twin Legend is offered as a finished motorcycle in three model variants:

basic
travel
rallye

Individual Configurations

Information on available parts and kits for DIY conversion of you own motorcycle and additional configuration options:

info

XRV 890 Africa Twin LEGEND


After a decade of unfulfilled hopes, AfricanQueens ends the wait for a worthy successor to Honda's most successful big-trail-bike with the introduction of the 'Legend'.
On occasion of our 20-year company anniversary we developed this modernised re-edition of the Africa Twin

The 'Twin' has always offered a reliable basis for customising to fit a variety of specialised assignments, whether as a trailbike, a café racer, as faithful companion for the world traveler or even as a rally machine. This is precisely why we are bringing her, the Legend, back to life in three different versions on this very, proven basis.

We have drawn all our knowledge and experience in racing and travel equipment into this project.
The core of the reworked and overhauled engine and frame of the Africa Twin is equipped with our best components and materials, which makes every Legend a fine limited edition bike, completed with roadworthy certification.
More powerful she has become ... lighter ... better suspensions she's got now ... known small weaknesses of the ancestor were remedied.
Of her famous dependability, she's lost non, and now shines in new splendor - and best in HRC colors.

The adventure stories around the Africa Twin are legendary ... And that is why our new Africa Twin series also bears the name:

„Legend”

Technical Specifications


MODEL

manufacturer

AfricanQueens

designation

XRV 890 AfricaTwin Legend (Rallye-Variante)





ENGINE



engine type

52º V-twin cylinder, 3 valve per cylinder, 4 stroke

displacement

890 cc

compression ratio

-

max. power output

85 h.p. / 63.4 kW at 7500 rpm

max. torque

94 Nm at 5900 rpm

max. speed

depending on final drive ratio

induction

2x 34.5 mm CV Keihin carburettors
modified

cooling system

liquid / oil cooled

fuel

two-star petrol / regular

starter

electric

gearbox

5 speed

ignition

electronic, 4x "NGK EVX" spark plugs
with platinum points





CHASSIS

suspension front

White Power USD 48 telescopic forks
Titaniumnitrit coating
280mm suspension travel

suspension rear

Öhlins shock absorber, type 3B
custom built, extended version
adjustable compression & rebound,
preload preset by spanner
278 mm suspension travel

seat height

99 cm

brakes front

320 mm hydraulic disc brake
with Brembo 2-piston calliper,
stainless steel braided lines

brakes rear

256 mm hydraulic disc
with Nissin 1-piston calliper,
stainless steel braided lines

wheel / tyre front

21 x 1.85 / 90/90-21

wheel / tyre rear

18 x MT 2.50 / 140/80 (90) - 18

tyre restrictions

non

wheelbase

1580mm +/- 10 mm

final drive

O-ring sealed chain

final drive reduction

17 x 53 (depending on application)

frame type

steel semi-double cradle





WEIGHTS & CAPACITIES

tank capacity

56 Litres (front 2 x 22; rear 2 x 6)

dry weight

approx. 189 kg

kerb weight

approx. 238 kg (incl. 56 litres of petrol)

max. allowed total weight

425 kg

Photo Galleries


XRV 890 Legend
Rallye Version

XRV 890 Legend
Rallye Version

XRV 890 Legend
Rallye II

XRV 890 Legend
without decals

XRV 890 Legend
Transanatolia 2015

XRV 890 Legend
Transanatolia 2015

XRV 890 Legend
MotorradAbenteuer Test

XRV 890 Legend
Test Ride Italy

XRV 890 Legend
Details


Parts & Kits



The Africa Twin Legend conversion consists of several parts & kits and can be configured for various applications. This also allows for a step-by-step conversion of your own bike if required.



For personal advice or an offer tailored to your individual requirements please feel free to contact us:

Further information and prices for AT Legend conversion parts can also be found here:
